Zephyr AK7848BS 48" Cypress Wall Outdoor
Cypress Features A Seamlessly Contoured, Fully Welded And Polished Exterior, Along With A Corrosion Resistant, 304-Grade Stainless Steel Canopy That Houses High-Performance Professional Stainless Steel Baffle Filters That Enhance Airflow And Are Dishwasher Safe. Three-Speed Metallic Knob Controls Withstand Extreme Heat And Moisture. Available With Dual-Level Halogen Lighting And An Extended 32" Depth For Even More Capture. An Optional 12" Duct Cover And Telescopic Duct Cover For 10' To 12' Ceilings Available.
  • 1200 CFM
  • Not Recirculating
  • Pro Baffle Filter
  • Stainless Steel
  • Vertical and Horizontal Ducting
  • Max Sones 9
  • 32" Depth
  • Dual-Level Lighting
  • Halogen Lighting
  • Metallic Knob Controls
  • Optional Duct Cover Extension Kit
  • Professional Baffle Filters
  • Vertical or Horizontal Ducting
UPC 646328004988
BLOWER INCLUDED YES/NO yes
INTERNAL BLOWER 1 CFM 1200
INTERNAL BLOWER 1 SONES 9
CONTROLS TYPE Metallic knob
BLOWER SPEEDS 3
AUTOMATIC DELAY-OFF no
CLEANAIR FUNCTION no
LIGHTS TYPE (INCLUDED) halogen
LIGHTS QUANTITY 4
WATTS PER BULB 35
LIGHTS LEVELS 2
FILTER TYPE pro baffle
DUCT DISCHARGE vertical or horizontal
DUCT SIZE, VERTICAL, INCHES 10
DUCT SIZE, HORIZONTAL, INCHES 10
MOUNTING HEIGHT ABOVE COOKTOP, INCHES 30 - 36
INPUT VOLTAGE 120
MAXIMUM AMPERAGE 8
NOMINAL WIDTH, INCHES 48
NET WIDTH, INCHES 47.875
DEPTH, INCHES 32
HEIGHT, INCHES (for chimney hoods, heights include duct covers) 18
WEIGHT, LBS 98.9
SHIPPING HEIGHT, INCHES 36.02
SHIPPING WIDTH, INCHES 51.18
SHIPPING LENGTH, INCHES 22.44
SHIPPING WEIGHT, LBS 120.2
