Kitchenaid KBFN502EBS 24.2 Cu. Ft. 42" Width Built-In Stainless French Door Refrigerator With Platinum Interior Design - Black Stainless Steel With Printshield™ Finish
Rebates &
Promotions
Preserva(R) Food Care System
Two independent cooling systems provide a dedicated refrigeration unit to help keep food fresh longer, and a separate system for frozen food. The FreshFlow Air Filter helps minimize odors while the FreshFlow Produce Preserver helps delay over-ripening.
Professionally-Inspired Design
combines a bold blend of professionally-inspired styling with sleek touches for the home. This beautiful side-by-side refrigeration unit features Satin Textured Handles and the KitchenAid(R) Badge, a symbol of uncompromised quality.
SatinGlide(R) System with Soft-Close
Add a luxury experience to the crisper drawers. The ball bearing rollers and glides allow effortless in-and-out movement even when fully loaded.
Fit System Limited Guarantee
This installation guarantee ensures KitchenAid Brand Built-in Refrigerators will replace your existing cabinet cut-out of a standard comparable built-in refrigerator model that is 36", 42" or 48" inch wide or kitchenAid will provide up to $300 for a professional to adjust your cabinets 1 .
- Automatic Ice Maker - Ensures that you have a constant supply of ice for entertaining.
- LED Lighting - Uses less energy than incandescent bulbs. Multiple lights are purposefully placed throughout the refrigerator and freezer, making it easy to find items at a glance.
- Intuitive Controls - Intuitive controls make it easy to precisely adjust the temperature of both the refrigerator and freezer.
- Adjustable Spill-Resistant Glass Shelves - are easy to clean and help prevent messes from spilling over into other parts of the refrigerator. The shelf edges are nano-etched with a finely textured surface that helps contain spills, and lets you use the whole shelf from edge-to-edge.
Specifications | |
Dimensions | |
Cabinet Width | 41-1/4 in |
Capacity | 24-17/100 |
Cutout Depth | 24.0 in |
Cutout Height | 83-1/2 in |
Cutout Width | 41-1/2 in |
Depth | 27-3/4 in |
Depth Closed Excluding Handles | 25-1/8 in |
Depth Closed Including Handles | 27-3/4 in |
Depth Excluding Doors | 23-3/8 in |
Depth With Door Open 90 Degree | 44-1/4 in |
Freezer Volume | 6.42 cu. ft. |
Height | 83-3/8 in |
Height To Top Of Cabinet | 83-3/8 in |
Refrigerator Volume | 17.75 cu. ft. |
Width | 42-1/4 in |
Configuration and Overview | |
ADA Compliant | No |
Advance Foam Insulation | 99.9% lower Global Warming Potential and Better Energy Performance |
CEE Tier | Tier I |
Counter Depth | Yes |
Prop 65 | CALIFORNIA RESIDENTS ONLY - WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov . |
UL | UL |
Appearance | |
Cabinet Finish | Smooth |
Door Finish | Smooth |
Door Style | Flat |
Handle Color | Stainless Steel |
Handle Material | Metal |
Hidden Hinge | Yes |
LCD Touch Screen | No |
Controls | |
Air Filter Indicator/Reset | No |
Automatic Defrost | Yes |
Door Ajar/Open Alarm | Yes |
Location of Controls | Interior Up Front |
Sabbath Mode | Yes |
Filter Details | |
Fresh Flow Air Filter | Yes |
Produce Preserver | Yes |
Water Filter Indicator/Reset | Yes |
Water Filter Location | Exterior |
Refrigerator Details | |
Lighting | LED |
Non Climate Control Drawers | 4 Half Width |
Number of Interior Shelves | 4 |
Dispenser Details | |
Dispenser Type | No Dispenser |
Certifications | |
Energy Star® Qualified | ENERGY STAR® Certified |
Freezer Compartment | |
Light | LED |
Configuration | |
Installation Configuration | Built-In |
Icemaker | |
Icemaker | Factory Installed |
Product Hierarchy | |
Flooring Program Codes | USKADBL |
