Kitchenaid WVU17UC0JW 30" Range Hood With Full-Width Grease Filters
Rebates &
Promotions
JennAir Curate Rebate - Receive up to 15% off in instant savings with purchase of 2 or more qualifying JennAir Appliances. Download Valid: 07/01/2024-12/31/2024
Choose the under cabinet range hood that fits your kitchen and your lifestyle. This vent hood features full-width grease filters to help keep the kitchen clean. Plus, this range hood with LED lights makes it easy to see what you're cooking. And with a 2-speed, 270 CFM motor class, you'll have the right amount of ventilation for every meal.
Full-width grease filters
Make cleanup easy with full-width grease filters that help keep the kitchen clean of unwanted grease and odors.
LED Task Lighting
Bright, long-lasting LED task lighting makes it easy to see what you're cooking.
2-speed, 270 CFM motor class
Two fan speeds provide the right amount of ventilation for every meal you prepare.
4.7 sones at low speed
At low speed, sound level is 4.7 sones. At maximum speed, sound level is 7.1 sones. (Based on vertical 7" round duct installation.)
FIT system
The FIT system helps reduce measuring, cutting and trim so that your hood is a perfect fit every time.
Flexible ventilation options
A convertible design lets you install almost anywhere. When external ventilation isn’t an option, the hood’s fan will recirculate air through filters that capture grease and cooking odors to help keep the kitchen clean.
Dimensions & Capacity
Width: 29 15/16"
Depth: 18 1/2"
Depth: 18 1/2"
- Full-width grease filters
- LED Task Lighting
- 2-speed, 270 CFM motor class
- 4.7 sones at low speed
- FIT system
Details | |
Style | Hoods |
Certifications | |
Kosher Consumer Friendly | Yes |
ADA Compliant | Yes |
Prop 65 | Standard |
Energy Star® Qualified | No |
UL | Yes |
Ventilation System | |
Vent Fan Location | Back |
Number of Speeds | 2 |
Sound Max Speed (Sones) | 7.1 |
Sound Min Speed (Sones) | 4.70 |
Exhaust Vent Location | Top |
Sound Min Speed (dB(A) | 65.7 |
Maximum Motor Exhaust Rating Cubic Feet per Minute (CFM) | 270 |
Vent Material | Plastic |
Venting | Exterior or Recirculating |
Sound Max Speed (dB(A) | 69.5 |
General | |
Accessory Relationships | Yes |
Dimensions | |
Carton Width(IN,inches) | 31 11/16 |
Canopy Height (IN,inches) | 4 15/16 |
Carton Height(IN,inches) | 20 15/16 |
Gross Weight(LB,pounds) | 15 |
Carton Depth(IN,inches) | 6 3/4 |
Electrical | |
Volts | 120 |
Watts | 60 |
Amps | 0.9 |
Power Cord Included | No |
Hz | 60 |
