Lg CBGJ3623D 36" Gas Cooktop With Ultraheat™ 20K Btu Burner
Rebates &
Promotions
5 Sealed Gas Burners
Five cooktop burners of varying sizes and power levels provide all the power and precision you need.
UltraHeat™ 20K BTU Burner
Turn up the power with a burner that can rapidly go to high heat for quick boiling, or turn down to a true simmer.
EasyClean® Stainless Steel Cooktop
Easily wipe away spills and splatters thanks to the specially-coated stainless-steel surface.
Auto Reignition
Auto reignition is a safety feature that automatically reignites the burners if the flame accidently goes out, preventing gas leakage and ensuring uninterrupted cooking.
Continuous Cast-Iron Grates
Not only do our heavy-duty, continuous cast-iron grates look great, but they also help provide even heating and a stable surface for your cookware.
This cooktop is designed for control and convenience, with Auto Reignition, EasyClean® Stainless Steel Cooktop, and front control knobs that make it simple to keep your kitchen looking its best. In addition, the five sealed burners and continuous cast-iron grates simplify meal preparation while providing an even and steady cooking surface for your cookware.
Dimensions & Capacity Width: 36"
Height: 3.75"
Depth: 21"
- UltraHeat™ 20K BTU Burner
- Cast-Iron Grates
- Auto Reignition
SUMMARY | |
Series | LG |
Type | 36' Gas Cooktop |
COOKTOP | |
Cooktop Burner Type | Sealed Gas Burner |
No. of Burners | 5 |
Burner/BTU - Left Rear | 10000/7500 |
Burner/BTU - Right Rear | 5000/4000 |
Burner/BTU - Left Front | 10000/7500 |
Burner/BTU - Right Front | 12000/10000 |
Burner/BTU - Center | 20000/12500 (warming zone) |
Burner Simmer / BTU - Left Rear | 1270 |
Burner Simmer / BTU - Right Rear | 670 |
Burner Simmer / BTU - Left Front | 1270 |
Burner Simmer / BTU - Right Front | 1270 |
Burner Simmer / BTU - Center | 1270 |
CONTROLS | |
Cooktop Control Type | Knob |
Control Location | Front Center |
DIMENSIONS/CLEARANCES/WEIGHT | |
Product (WxHxD) | 36' x 3 3/4' x 21 11/16' |
Cut-Out (WxHxD) | 33 7/8' x 3 3/4' x 19 5/8' |
Shipping Dimensions (W x H x D) | 40 7/16' x 10 5/32' x 25 25/32' |
Weight (Product) | 52 lbs |
Shipping Weight (lbs) | 61 |
POWER/RATINGS | |
kW at 120V | 120V 60Hz / 0.12A |
Requirements | 120 V / 60Hz AC |
THINQ® SMART FEATURES | |
ThinQ® | No |
Wi-Fi Connectivity | No |
ACCESSORIES | |
Griddle Plate | No |
Conversion Kit | Yes |
WARRANTY/UPC | |
Parts & Labor | 1 Year |
UPC | 048231345330 |
APPEARANCE | |
All Available Colors | Stainless Steel / Black Stainless Steel |
Owner's Manual English 3,643K 04/21/2023
Owner's Manual Spanish 3,635K 04/21/2023
