Maytag MGC9536DS 36-Inch Wide Gas Cooktop With Duraguard Protective Finish
Rebates &
Promotions
Power Simmer Dual Stack Burner
The Power simmer dual stacked burner gives you precise control over your cooktop, allowing you to boil water rapidly or gently hold low temperatures to simmer sauces - all with one burner.
DuraGuard Protective Finish
The DuraGuard protective finish keeps the cooktop surface lookin' like new and cleans with ease year after year.
Simmer Burner with Melt Cap
The simmer burner allows for adjustable heat control from 800 to 5,000 BTUs. The addition of a melt cap on the burner diffuses the flame for low-heat melting or warming without the need for constant monitoring.
DuraClean Continuous Cast Iron Grates
Dishwasher safe DuraClean cast-iron grates let pots and pans smoothly slide around the cooktop for fewer spills and easier transitions from burner to burner.
Power Burner
The Power Burner allows for a slow, even saute and the intense heat for a seared, juicy steak.
Sealed Surface Burners
Sealed surface burners help prevent spills from leaking into the interior of your cooktop making clean up faster and easier.
Take charge of your cooking experience with Maytag® gas cooktops. The 18,000-BTU Power™ Burner delivers heat on demand to sear flavor and juices into main dishes, while the Power Simmer dual stacked burner on this 36-inch gas cooktop allows for delicate control of savory sauces and soups. And this 5-burner cooktop will clean with ease through years of use thanks to features like the DuraGuard™ protective finish and heavy-duty DuraClean™ continuous cast-iron grates.
- Power Simmer Dual Stack Burner The Power simmer dual stacked burner gives you precise control over your cooktop, allowing you to boil water rapidly or gently hold low temperatures to simmer sauces - all with one burner.
- DuraGuard Protective Finish The DuraGuard protective finish keeps the cooktop surface lookin' like new and cleans with ease year after year.
- Simmer Burner with Melt Cap The simmer burner allows for adjustable heat control from 800 to 5,000 BTUs. The addition of a melt cap on the burner diffuses the flame for low-heat melting or warming without the need for constant monitoring.
- DuraClean Continuous Cast Iron Grates Dishwasher safe DuraClean cast-iron grates let pots and pans smoothly slide around the cooktop for fewer spills and easier transitions from burner to burner.
- Power Burner The Power Burner allows for a slow, even saute and the intense heat for a seared, juicy steak.
- Sealed Surface Burners Sealed surface burners help prevent spills from leaking into the interior of your cooktop making clean up faster and easier.
- 5 Burners With an extra burner you have the flexibility to prepare all your meals without juggling pots and pans.
- Designed, Engineered, and Assembled in the USA From Tennessee to you, these cooktops are designed, engineered and assembled in the U.S.A.
- 10 Year Limited Parts Warranty With a 10-year limited parts warranty on the cooktop burners and cast-iron metal grates, we built these cooktops tough enough to keep cookin' for years.
Dimensions | |
Cutout Depth | 19-1/2 in |
Cutout Depth Max | 20.0 in |
Cutout Depth Min | 19.0 in |
Cutout Height | 5-1/4 in |
Cutout Width | 34-5/16 in |
Cutout Width Max | 35-1/4 in |
Cutout Width Min | 33-7/8 in |
Depth | 21.0 in |
Height | 3-11/16 in |
Maximum Height | 4.0 in |
Width | 36.0 in |
Cooktop Type | Standard |
Fuel Type | Gas |
Installs Over Built-In Oven | Yes |
LP Convertible | Yes - Kit Included |
Power Boost | No |
Size | 36 in |
Infinite Heat Controls | Yes |
Knob Color | Stainless Steel |
Knob Type | Metal |
Location of Controls | Front |
Automatic Pan Detection | No |
Cooktop Element Style | Sealed Burner |
Cooktop Surface Color | Color Coordinated |
Downdraft Vent | No |
Grate Details | Dishwasher Safe, Matte Finish, Continuous, Cast Iron Grates |
Heating Element On Indicator Light | No |
Hot Surface Indicator Light | No |
Ignition Type | Direct Spark Ignition |
Left Rear Element-Burner Type | Sealed Burner |
Number of Cooking Element-Burners | 5 |
Number of Grates | 3 |
Right Front Element-Burner Type | Sealed Burner |
Digital Display | No |
Prop 65 | CALIFORNIA RESIDENTS ONLY - WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov . |
Power Cord Included | Yes |
Features | DuraGuard Protective Finish, Power Burner, Simmer Burner with Melt Cap, ADA Compliant |
Power Outage Compatible | Yes |
GPC Code | 10001951 |
IsInvoiceUnit | true |
IsOrderableUnit | true |
Product Type | EA |
UDEX | 1100400623 |
isBaseUnit | true |
isConsumerUnit | true |
Cooktop Surface Material | Stainless/Porcelain Coated Steel |
DuraGuard_Protective Finish
Power Burner Gas
Use & Care Guide
Warranty Page - W10648065-W
Instruction Sheet
Dimension Guide
Warranty Page
Misc
Owners Manual Full Manual
