Summit FF511LBIMEDADA Ada Compliant 20" Wide All-Refrigerator For Built-In Use, With Internal Fan, Lock, Temperature Alarm, And Hospital Grade Plug
Accucold By Summit Appliance Offers The Med Series All-Refrigerators, A Complete Line That Comes Fully Featured For Stabilized Temperature Performance For Use In Medical, Scientific, Pharmaceutical, And Laboratory Institutions. The Ff511Lbimedada Is A 20" Wide All-Refrigerator Designed For Built-In Use Under Lower Ada Compliant Counters. It Uses Automatic Defrost Operation Complete With An Internal Fan For Even Cold Air Distribution Throughout The 4.1 Cu.Ft. Interior. Inside, A Digital Thermostat Allows Easy And Intuitive Temperature Management. The Door Includes A Front Lock And Nist Calibrated High Temperature Warning Alarm That Also Displays The Current And High/Low Temperatures. Additional Features Include An Interior Light, Adjustable Shelves, And Hospital Grade Cord With A 'Green Dot' Plug For Added Safety In High Traffic Areas. The Ff511Lbimedada Can Be Used Built-In Or Freestanding And Paired With The Matching Fs407Lbimedada All-Freezer. *Note: This Unit'S Thermostat Is Pre-Set For Celsius. If You Prefer Fahrenheit, Add Complimentary Option Dtmedf Or Let Your Sales Representative Know Upon Order.
- ADA compliant: 32" high to fit under lower ADA compliant counters
- Slim 20" width: Full 4.1 cu.ft. capacity inside conveniently slim footprint
- Built-in capable: Make the best use of space by installing your appliance under the counter
- Factory installed lock: Keyed security on the refrigerator door
- High temperature alarm: Warns of temperature fluctuations and includes an external temperature readout on the door
- NIST calibrated temperature display: Alarm includes continuous NIST calibrated display of the current interior and high/low temperature, and can be switched from Celsius to Fahrenheit at the touch of a button
- Digital thermostat: Electronic controls (located inside the refrigerator) ensure easy and intuitive temperature management
- Hospital grade cord with 'green dot' plug: Secure three-pronged cord for added unit safety
- Automatic defrost: Reduced maintenance with auto defrost system
- Internal fan with heat sink: Fan-forced cooling ensures the unit is evenly cooled from top to bottom
- Adjustable shelves: Rearrange refrigerator space to accommodate all sizes or remove shelves for simple cleanup
- Interior light: Turn the light on and off with a convenient rocker switch
- Flat door liner: Easy to clean, with more depth for storage
- Matching freezer available: Pair with FS407LBIMEDADA for a complete ADA compliant undercounter set
- Fully finished white cabinet: Allows the unit to be used freestanding
- 100% CFC Free: Environmentally friendly design with no ozone-damaging chemicals
| Overview | |
| Height of Cabinet | 32.0' (81 cm) |
| Height to Hinge Cap | 32.5' (83 cm) |
| Width | 19.25' (49 cm) |
| Depth | 22.25' (57 cm) |
| Depth with Handle | 23.0' (58 cm) |
| Depth with door at 90° | 39.5' (100 cm) |
| Capacity | 4.1 cu.ft. (116 L) |
| Defrost Type | Automatic |
| Door | White |
| Cabinet | White |
| US Electrical Safety | ETL |
| Canadian Electrical Safety | ETL-C |
| Amps | 1.4 |
| Voltage/Frequency | 115 V AC/60 Hz |
| Weight | 64.0 lbs. (29 kg) |
| Shipping Weight | 67.0 lbs. (30 kg) |
| Parts & Labor Warranty | 1 Year |
| Compressor Warranty | 5 Years |
| Refrigerator Features | |
| Door Swing | RHD |
| Reversible | Factory Reversible |
| Shelf Type | Wire |
| Shelf Qty | 3 |
| Adjustable Shelves | Yes |
| Thermostat Type | Digital |
| Fan Type | Interior |
| Refrigerant Type | R134a |
| Refrigerant Amount | 1.75oz. |
| High Side PSI | 205.0 |
| Low Side PSI | 103.0 |
| Level Legs Qty | 2 |
| Interior Light | Yes |
| Dimensions | |
| Interior Height | 28.5' (72 cm) |
| Interior Width | 15.75' (40 cm) |
| Interior Depth | 18.0' (46 cm) |
| Compressor Step Height | 8.0' (20 cm) |
| Compressor Step Width | 17.0' (43 cm) |
| Compressor Step Depth | 6.75' (17 cm) |
| Handle | |
| CP Full-Length Copper Pipe Handle Factory-installed full-length handle made from pure copper for antimicrobial protection | TBC Copper Towel Bar Handle Factory-installed handle made from pure copper for antimicrobial protection |
| Exterior | |
| Agion Door Treat the door with Agion silver antimicrobial coating to reduce the growth of bacteria, fungi, molds, and other destructive microbes on appliance surface | DL1 - Factory installed data logger USB Temperature Logger records interior temperature in 15 minute intervals to a USB flash drive for analysis on a PC or Mac |
| Latch for door Door latch requires manual release to open door. Ideal for yachts, RVs, coach buses, and other vehicles. | LHD - Left hand door swing Door reversal to left hand swing |
| ODA - Open door alarm Add an open door alarm to audibly buzz when the door is left ajar. | SCD - Self-closing door Protect interior contents and reduce energy waste with the Self Closing Door Option |
| Extra key Extra keys available for purchase | DTMEDF - Digital thermostat with Fahrenheit readout Change thermostat to read in Fahrenheit (no charge) |
| DL2B - Factory installed NIST calibrated digital data logger (DDL) USB digital data logger with internal memory, user | set recording intervals, high/low temperature alarm, and NIST calibrated temperature readout |
| Lock | |
| AC Keypad Keypad door lock powered by appliance power cord for keyless security | KEYPAD Battery-powered keypad door lock installed for keyless security |
