Summit FF63BBIFRADA Ada Compliant Built-In Undercounter All-Refrigerator For Residential Use, Auto Defrost With Stainless Steel Door Frame For Slide-In Panels And Black Cabinet
32" Height For Use Under Lower Ada Compliant Counters Flexible Design Allows Built-In Or Freestanding Use In 24" Spaces Stainless Steel Door Frame Accepts Slide-In Panels For A Custom Look Deluxe Interior With Glass Shelves, Door Storage, And A Scalloped Wine Shelf Automatic Defrost Ensures Minimum User Maintenance Made In Europe Summit Offers The Industry's Largest Selection Of Ada Compliant Built-In Undercounter Refrigeration, With A Range Of Choices To Best Meet The Needs Of Any Home Or Facility With Height Limitations. The Ff63Bbiada Series Includes Fully Featured All-Refrigerators For Built-In Or Freestanding Use In Residential Settings. Sized With A 24" Footprint And 32" Height, The Front-Breathing Ff63Bbifrada All-Refrigerator Can Be Built-In Under Lower Ada Compliant Counters Or Used Freestanding. The User-Reversible Door Includes A Two-Piece Stainless Steel Frame Designed To Accept Slide-In Panels, Letting You Customize Your Unit To Best Fit Its Setting (Panel Size: 23" W X 28" H At Up To 1/4" Thick). A Sleek Stainless Steel Handle Is Included. This Model Has A Black Cabinet. Inside, The Ff63Bbifrada Utilizes Automatic Defrost Operation To Ensure Minimum User Maintenance. The 5.5 Cu.Ft. Interior Offers More Storage Space Than Most Models In This Size Class. Adjustable Glass Shelves Ensure Spill-Proof Storage, While A Large Crisper Drawer Is Ideal For Keeping Produce At Its Best. A Removable Wine Shelf Lets You Keep Bottles Securely In Place. The Door Includes Three Storage Racks For Condiments And Tall Bottles. The Seamless Interior Also Features A Dial Thermostat And Automatic Light. Designed And Constructed In Europe, The Ff63Bbifrada Brings Reliable Cold Storage To Any Setting In Need Of A Quality Refrigerator In An Ada Compliant Height.
- ADA compliant : 32" height to fit under lower ADA compliant counters
- Slim undercounter dimensions : Ideal 24" footprint offers full 5.5 cu.ft. storage capacity in a slim fit
- Built-in capable : Make the best use of space by installing your appliance under the counter and flush with other cabinets
- Stainless steel door frame : Two-piece U-shaped door frame in stainless steel accepts slide-in panels (sized 23" W x 28" H at up to 1/4" thick), allowing users to create a custom look to match or complement adjacent cabinetry
- Automatic defrost : Reduced maintenance with auto defrost system
- Adjustable glass shelves : Rearrange your refrigerator space to accommodate all shapes and sizes or remove shelves for a simple clean-up
- Door storage : Store tall bottles and condiments right on the door for convenient access
- Wine shelf : Removable scalloped wine shelf is included to store champagne and wine bottles
- Fruit and vegetable crisper : Get the longest life and best taste out of produce by storing greens in a convenient slide drawer
- Interior light : Automatically illuminates when you open the door
- One piece interior liner : Enjoy easy clean-up with a seamless liner that won't hold a mess in hidden crevices
- Hidden evaporator : Cold wall design with hidden evaporator creates a seamless, easy to clean interior
- Adjustable thermostat : Dial thermostat located inside for easy temperature management
- Pro style handle : Stainless steel handle adds an attractive touch
- Reversible door : User-reversible door swing for added flexibility
- Fully finished black cabinet : Allows the refrigerator to be used as a freestanding model
- 100% CFC free : Environmentally friendly design without ozone-damaging chemicals
Overview | |
Height of Cabinet | 32.0' (81 cm) |
Height to Hinge Cap | 32.25' (82 cm) |
Width | 23.63' (60 cm) |
Depth | 23.0' (58 cm) |
Depth with door at 90° | 45.38' (115 cm) |
Capacity | 5.5 cu.ft. (156 L) |
Defrost Type | Automatic |
Door | Panel-Ready |
Cabinet | Black |
US Electrical Safety | UL |
Canadian Electrical Safety | ULC |
Energy Usage/Year | 307.0kWh/year |
Amps | 1.0 |
Voltage/Frequency | 115 V AC/60 Hz |
Weight | 100.0 lbs. (45 kg) |
Shipping Weight | 105.0 lbs. (48 kg) |
Estimated Time to Ship | 2 to 4 days |
Parts & Labor Warranty | 1 Year |
Compressor Warranty | 5 Years |
Refrigerator Features | |
Door Swing | RHD |
Reversible | Yes |
Crisper Qty | 1 |
Crisper Finish | Opaque |
Crisper Cover | Glass |
Shelf Type | Glass |
Shelf Qty | 3 |
Full Door Shelf Qty | 3 |
Wine Bottle Shelves | Yes |
Thermostat Type | Dial |
Fan Type | Exterior |
Refrigerant Type | R134a |
Refrigerant Amount | 1.7oz. |
High Side PSI | 285.0 |
Low Side PSI | 70.0 |
Interior Light | Yes |
Dimensions | |
Interior Height | 26.25' (67 cm) |
Interior Width | 21.0' (53 cm) |
Interior Depth | 18.0' (46 cm) |
Compressor Step Height | 5.5' (14 cm) |
Compressor Step Width | 21.0' (53 cm) |
Compressor Step Depth | 6.0' (15 cm) |
Exterior | |
DL2B - Factory installed NIST calibrated digital data logger (DDL) | TT - Installed thermometer |
PH - Probe Hole | DT - Digital thermostat |
Alarm | SCD - Self-closing door |
ODA - Open door alarm | LHD - Left hand door swing |
Latch for door | SSK |
HUM - Humidity sensor | HG - Hospital grade cord |
DL1 - Factory installed data logger | - |
Lock | |
KEYPAD | AC Keypad |
Interior | |
FCGP internal fan with gel packs | FC - Internal Fan |
