Summit SBC58WHBIADANK 24" Wide Built-In Kegerator, Ada Compliant
Summit Commercial Brings Unique Appliance Choices To Ada Compliant Settings With A New Line Of Commercial Beer Dispensers Made In Europe. Sized At 32 Inches High, The Sbc58Whbiadank Is Designed To Fit Under Lower Ada Compliant Counters. The Front-Breathing Design Allows Built-In Installation, While The Fully Finished Cabinet Also Enables Freestanding Use. This Unit Comes In A Clean White Finish Accented By A Stainless Steel Kickplate And Pro Style Handle. We Include A Removable Two-Piece Stainless Steel Drip Tray For Cleaner Service. This Unit Does Not Include Any Tapping Equipment, Allowing "Do-It-Yourselfers" To Customize Their Draft System. Inside, The Sbc58Whbiadank Is Designed To Hold Two 1/6 (Sixtel) Kegs (Note: Interior Does Not Accommodate A Standard Half Barrel). Automatic Defrost Ensures Easy User Maintenance, With A Seamless Interior For Easier Cleaning. The Stainless Steel Floor Offers Added Durability When Loading Kegs. This Unit Includes An Interior Light With An On/Off Rocker Switch And A Dial Thermostat For Easy And Intuitive Temperature Management. A Co2 Tank Bracket Is Located Inside, Allowing You To Keep The Tank In The Unit And Save On Exterior Depth. The Sbc58Whbiadank Is Etl-S Listed To Nsf-7 Commercial Standards. Additional Ada Compliant European Kegerators Are Available With Stainless Steel, Panel-Ready, Or Glass Door, As Well As Tap Kits That Allow You To Serve Beer, Wine, Coffee, Or Kombucha From This Unit. Browse Our Complete Line For More Choices.
- Sized at 32 inches high (32.25 to hinge cap) for installation under lower ADA compliant counters
- ETL-S listed to NSF-7 commercial standards and meets UL-471 for use in foodservice settings
- Front-breathing design allows fully recessed installation under counters
- Install your own tapping equipment to create a customized beer cooler
- Classic and clean look suits any setting
- Solid tube style handle in brushed stainless steel offers a modern accent to the white door finish
- Interior dial thermostat ensures easy temperature management
- No-frost operation for minimum user maintenance
- Removable two-piece drip tray included for added convenience
- Turn the light on when you need it and off when you're done with a convenient rocker switch
- Bracket is installed inside, allowing you to save on depth by keeping the tank behind your kegs
- Interior includes steel cover to protect the floor when loading kegs
- Easy clean-up with a seamless liner that won't hold a mess in hidden crevices
- Cold wall design with hidden evaporator and seamless interior
- Allows the unit to be used freestanding
- Environmentally friendly design without ozone-damaging chemicals
- Environmentally friendly hydrocarbon-based refrigerant for a greener footprint that meets current CARB regulations
Overview | |
Height of Cabinet | 32.0' (81 cm) |
Height to Hinge Cap | 32.25' (82 cm) |
Width | 23.63' (60 cm) |
Depth | 22.75' (58 cm) |
Depth with Handle | 24.75' (63 cm) |
Depth with door at 90° | 45.0' (114 cm) |
Capacity | 5.5 cu.ft. (156 L) |
Defrost Type | Automatic |
Door | White |
Cabinet | White |
US Electrical Safety | ETL |
Canadian Electrical Safety | ETL-C |
Sanitation | ETL-S |
Amps | 1.2 |
Voltage/Frequency | 115 V AC/60 Hz |
Weight | 100.0 lbs. (45 kg) |
Shipping Weight | 110.0 lbs. (50 kg) |
Parts & Labor Warranty | 1 Year |
Compressor Warranty | 5 Years |
UPC | 761101086514 |
Kegerator | |
Door Swing | RHD |
Reversible | Factory Reversible |
Thermostat Type | Dial |
Interior Light | Yes |
Fan Type | Exterior |
Refrigerant | R600a |
Refrigerant Amount | 0.64 oz. |
High Side PSI | 180.0 |
Low Side PSI | 80.0 |
Inter Height | 25.75' (65 cm) |
Interior Width | 21.0' (53 cm) |
Interior Depth | 17.75' (45 cm) |
Compressor Step Height | 6.5' (17 cm) |
Compressor Step Width | 21.0' (53 cm) |
Compressor Step Depth | 5.5' (14 cm) |
Temperature Range | 34 to 43 F |
